Rated Evaporation Capacity :0.5~25t/h
Working Pressure :0.2~2.5Mpa
Waste Heat Utilization Rate :≧70%
Application :Glass factories
Application : Chemical Industry Boiler ,Pharmaceuticals Industry ,Sugar Industry Boiler ,Paper Processing Industry
Email : info@xinliboiler.com
Glass furnace flue gas waste heat boiler is an equipment with the use of 600 ℃ flue gas in glass furnace for cogeneration or steam. By using the device, the heat production system can further improve heat utilization rate of more than 70%, the high temperature waste heat resource is fully recovered in the glass furnace.
Xinli Boiler has developed the double drum exhaust type of vertical natural circulation pipe waste heat boiler and the horizontal single-pipe waste heat boiler, long life, easy maintenance, economic security, reliable. This is fully applicable for float glass furnace production line with the use of heavy oil or natural gas.
This boiler employs uniform velocity and low velocity design, to reduce the power consumption.
This boiler is U-model structure, long life and simple maintenance.
Large diameter centralized downcomer, guarantee water circulation safe and reliable, reduce resistance.
Model | Rated Evaporation Capacity (t/h) | Rated Pressure (MPa) | Steam Temperature (℃) | Feed Water Temperature (℃) |
Q10/450-1.3-1.25 | 1.3 | 1.25 | 194 | 20 |
QC45/372-4.7-1.35/310 | 4.7 | 1.35 | 310 | 104 |
Q120/530-8.6-0.8 | 8.6 | 0.8 | 175 | 104 |
Q96/480-13.2-2.3/430 | 13.2 | 2.3 | 430 | 150 |
Q100/510-14-2.6/420 | 14 | 2.6 | 420 | 104 |
Q108/500-15-0.7 | 15 | 0.7 | 170 | 20 |
Q110/510-16.4-2.4/430 | 16.4 | 2.4 | 430 | 138 |
Q145/510-21.2-2.6/430 | 21.2 | 2.6 | 430 | 138 |
Note: Xinli Boiler could customize design the waste heat recovery boiler based on the actual demand |
